Parker AC10 series User Manual

Parameter Reference 15-1
AC10 Inverter
Chapter 15 Parameter Reference
Basic parameters: F100-F160
Function
Code
Function
Definition
Setting Range Mfr’s Value Change
F100 User’s Password 0～9999 √
F102 Inverter’s Rated Current (A)
Subject to
inverter model
О
F103 Inverter Power (kW)
Subject to
inverter model
О
F104 Reserved
F105 Software Edition No.
Subject to
inverter model
△
F106 Control Mode
Setting range:
0:Sensorless vector control
(SVC);
1: Reserved;
2: VVVF
3: Vector control 1
6 (Synchronous motor control
mode)
2
╳
F107 Password Valid or Not 0: invalid; 1: valid 0 √
F108 Setting User’s Password
0～9999
8 √
F109 Starting Frequency (Hz)
0.0～10.00Hz
0.0 √
F110 Holding Time of Starting Frequency (S) 0.0～999.9 0.0 √
F111 Max Frequency (Hz)
F113～590.0Hz
50.00 √
F112 Min Frequency (Hz)
0.00Hz～F113
0.50 √
F113 Target Frequency (Hz)
F112～F111
50.00 √
F114 1
st
Acceleration Time (S)
0.1～3000
subject to
inverter
model
√
F115 1
st
Deceleration Time (S)
0.1～3000
√
F116 2
nd
Acceleration Time (S)
0.1～3000
√
F117 2
nd
Deceleration Time (S)
0.1～3000
√
F118 Base Frequency (Hz)
15.00～590.0
50.00
╳
F119 Reference of Setting Accel/Decel Time
0: 0~50.00Hz
1: 0~ F111
0
╳
F120 Forward/Reverse Switchover Dead-Time 0.0～3000 0.0 √
F121 Reserved
F122 Reverse Running Forbidden 0: invalid; 1: valid 0
╳
F123
Minus Frequency is Valid in the Mode of Combined
Speed Control.
0：Invalid；1：valid
0
╳
F124 Jogging Frequency
F112～F111
5.00Hz √
F125 Jogging Acceleration Time
0.1～3000S
subject to
inverter
model
√
F126 Jogging Deceleration Time
0.1～3000S
√
