Parker AC10 series User Manual

11-1 Technical Specifications
AC10 Inverter
Chapter 11 Technical Specifications
11.1 Selection of Braking Resistance
Inverter Models
Applicable Motor Power（kW）
Applicable Braking
Resistance
16G-11-0025-BF
16G-31-0025-BF
0.4
150W/60Ω
16G-11-0045-BF
16G-31-0045-BF
0.75
16G-11-0070-BF
16G-31-0070-BF
1.5
16G-11-0100-BF
16G-31-0100-BF
2.2
16G-41-0020-BF 0.75 80W/200Ω
16G-41-0040-BF 1.5 80W/150Ω
16G-41-0065-BF 2.2
150W/150Ω
16G-41-0080-BF 3.7
16G-41-0090-BF 4.0
16G-42-0120-BF 5.5 250W/120Ω
16G-42-0160-BF 7.5 500W/120Ω
16G-43-0230-BF 11 1kW/90Ω
16G-43-0320-BF
15 1.5kW/80Ω
Note: in the occasion of large inertia load, if the braking resistor heat is excessive, use a larger
power of resistor than the recommended resistor.
