6-3 The Menu Organisation
AC10 Inverter
6.3 Panel Display
Table 6-4 Items and Remarks Displayed on the Panel
Items
Remarks
HF-0
This Item will be displayed when you press “M” in stopping status, which
indicates jogging operation is valid. But HF-0 will be displayed only after
you change the value of F132.
-HF- It stands for resetting process and will display target frequency after reset.
OC, OC1, OE, OL1,
OL2, OH, LU, PF0, PF1,
CE, FL
Fault code, indicating “over-current OC”, “over-current OC1”,
“over-voltage”, “inverter over-load”, “motor over-load” “over-heat”,
“under-voltage for input”, “phase loss for output”, “phase loss for input”
“Communication error”, “Flycatching fault” respectively.
AErr, Err5
Analog line disconnected, PID parameters are set wrong,
ESP
During two-line/three line running mode, “stop/reset” key is pressed or
external coast stop terminal is closed, ESP will be displayed.
F152
Function code (parameter code).
10.00
Indicating inverter’s current running frequency (or rotate speed) and
parameter setting values, etc.
Flashing in stopping status to display target frequency.
0.
Holding time when changing the running direction. When “Stop” or “Free
Stop” command is executed, the holding time can be cancelled.
A100、U100
Output current (100A) and output voltage (100V). Keep one digit of decimal
when current is below 100A.
b*.*
PID feedback value is displayed.
o*.*
PID given value is displayed.
L***
Linear speed is displayed.
H *
Heatsink temperature is displayed.
