8-7 Operation and Simple Running
AC10 Inverter
ii. Press the “M” key, to enter the programming menu.
iii. Study the parameters of the motor: the operation process is the same as that of
example 1. (Refer to 8.3.1 for tuning of the motor).
iv. Set functional parameters of the inverter:
Function code Values
F111 50.00
F203 0
F208 1
v. Close the switch DI3, the inverter starts forward running;
vi. During running, current frequency of the inverter can be changed by pressing ▲ or
▼;
vii. During running, switch off the switch DI3, then close the switch DI4, the running
direction of the motor will be changed (Note: The user should set the dead time of
forward and reverse running F120 on the basis of the load. If it was too short, OC
protection of the inverter may occur.)
viii. Switch off the switches DI3 and DI4, the motor will decelerate until it stops running;
ix. Switch off the isolator, and power off the inverter.
8.3.3 Operation process of jogging operation using the keypad panel
i. Connect the wires in accordance with Figure 8-1. After having checked the wiring
successfully, switch on the isolator, and power on the inverter;
ii. Press the “M” key, to enter the programming menu.
iii. Study the parameters of the motor: the operation process is the same as that of
example 1. (Refer to 8.3.1 for tuning of the motor).
iv. Set functional parameters of the inverter:
Function code Values
F124 5.00
F125 30
F126 30
F132 1
F202 0
v. Press and hold the “Run” key until the motor is accelerated to the jogging frequency,
and maintain the status of jogging operation.
vi. Release the “Run” key. The motor will decelerate until jogging operation is stopped;
vii. Switch off the isolator, and power off the inverter.
