The Menu Organisation 6-2
AC10 Inverter
6.2 Function Codes Switchover in/between Code-Groups
It has more than 300 parameters (function codes) available to user, divided into sections as
indicated in Table 6-3.
Table 6-3 Function Code Partition
Group Name
Function
Code Range
Group
No.
Group Name
Function
Code Range
Group
No.
Basic Parameters
F100～F160
1
Timing control and
protection
function
F700～F770
7
Run Control Mode
F200～F280
2
Parameters of the
motor
F800～F850
8
Multi-functional
input/output terminal
F300～F340 3
Communication
function
F900～F930 9
Analog signals and
pulse of input/output
F400～F480
4
PID parameter
setting
FA00～FA80
10
Multi-stage speed
Parameters
F500～F580
5 Torque control FC00~FC40 11
Subsidiary function F600～F670 6
As parameter setting can take time due to numerous function codes, such function is specially
designed as “Function Code Switchover in a Code Group or between Two Code-Groups” so
that parameters setting becomes convenient and simple.
Press “M” key so that the keypad controller will display function code. If user presses “▲” or “▼”
key, the function code will circularly keep increasing or decreasing by degrees within the group;
if user presses the key again, the function code will change circularly between two code
groups when operating the “▲” or “▼” key.
F1-00 is displayed,
the last “0” in
F1-00 is flashing.
F1-00~F1-60 can be
displayed.
▲or
▼
key
Press
key
Press
▲or
▼
key
Currently showing
50.00
Press M key
1 in F1-00 is
flashing.
Press
F1-00~FC-00 can be
displayed.
