Parameter Reference 15-15
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F870 Motor back electromotive force
0.1999.9 (valid value between
lines)
Subject to
inverter
model
F871 D-axis inductance
0.01655.35
Subject to
inverter
model
F872 Q-axis inductance
0.01655.35
Subject to
inverter
model
F876
Stator resistance
(phase resistance)
0.00165.535 (phase resistor)
20.0
F877
Injection current without load
(%)
0.0100.0 %
0.0
F878
Cut-off point of injection current
compensation without load(%)
0.050.0 %
10.0
F880 PCE detection time(S)
0.050.0 %
0.2
0.010.0 S
Communication parameter: F900-F930
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F900 Communication Address
1~255: single inverter address
0: broadcast address
1
F901 Communication Mode
1: ASCII
2: RTU
1
F902 Reserved
F903
Parity Check 0: Invalid
1: Odd
2: Even
0
F904 Baud Rate
0: 1200
1: 2400
2: 4800
3: 9600
4: 19200
5: 38400
6: 57600
3
F905 Communication Timeout 0.0~3000.0 0.0
F906-
F930
Reserved
PID parameters: FA00-FA80
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
FA01 PID reference signal source 0: FA04 1: AI1 2: AI2 0
