Parker AC10 series User Manual

14-4 Compliance
AC10 Inverter
14.3.1 Radiated
The standards have common roots (CISPR 11 & CISPR14) so there is some commonality in
the test levels applied in different environments.
Relationship Between Standards
Standards
Limits*
Product Specific
Generic
EN 61800-3
EN61000-6-3
EN61000-6-4
Category C1 Equivalent Not applicable
30 – 230MHZ 30dB(µV/m)
230 - 1000MHz 37dB(µV/m)
Category C2 Not applicable Equivalent
30 – 230MHZ 40dB(µV/m)
230 - 1000MHz 47dB(µV/m)
Category C3
These limits have no relationships
with the generic standards.
30 – 230MHZ 50dB(µV/m)
230 - 1000MHz 60dB(µV/m)
*Adjusted for 10m
Radiated Emissions Profile
EN61800-3 - Limits for electromagnetic radiation disturbance in the frequency band 30 MHz to
1000 MHz
Frequency band
MHz
Category C1 Category C2
Electric field strength
component
Quasi-peak dB(V/m)
Electric field strength
component
Quasi-peak dB(V/m)
30 δ f δ 230
30 40
230 < f δ 1 000 37 47
NOTE: Measurement distance 10 m.
For category C1, if the field strength measurement at 10 m cannot be made because of high
ambient noise levels or for other reasons, measurement may be made at 3 m. If the 3 m
distance is used, the measurement result obtained shall be normalised to 10 m by
subtracting 10 dB from the result. In this case, care should be taken to avoid near field
effects, particularly when the PDS (Power Drive System) is not of an appropriately small size,
and at frequencies near 30 MHz.
When multiple drives are used 3dB attenuation per drive needs to be added.
