15-8 Parameter Reference
AC10 Inverter
Function
Code
Function
Definition
Setting Range Mfr’s Value
Change
F329 Reserved
F330 Diagnostics of DIX terminal
△
F331
Monitoring AI1
△
F332
Monitoring AI2
△
F335
Relay output simulation Setting range:
0：Output active.
1：Output inactive.
0
╳
F336
DO1 output simulation 0
╳
F338
AO1 output simulation
Setting range: 0～4095
0
╳
F340 Selection of terminal negative logic
0: Invalid
1: DI1 negative logic
2: DI2 negative logic
4: DI3 negative logic
8: DI4 negative logic
16: DI5 negative logic
0 √
Analog Input and Output: F400-F480
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F400
Lower limit of AI1 channel input
0.00
～F402
0.01
√
F401
Corresponding setting for lower limit of AI1
input
0
～F403
1.00
√
F402
Upper limit of AI1 channel input
F400
～10.00
10.00
√
F403
Corresponding setting for upper limit of AI1
input
Max
（1.00，F401）～2.00
2.00
√
F404
AI1 channel proportional gain K1
0.0
～10.0
1.0
√
F405
AI1 filtering time constant
0.01
～10.0
0.10
√
F406
Lower limit of AI2 channel input
0.00
～F408
0.01V
√
F407
Corresponding setting for lower limit of AI2
input
0
～F409
1.00
√
F408
Upper limit of AI2 channel input
F406
～10.00
10.00V
√
F409
Corresponding setting for upper limit of
AI2
input
Max
（1.00，F407）～2.00
2.00
√
F410
AI2 channel proportional gain K2
0.0
～10.0
1.0
√
F411
AI2 filtering time constant
0.01
～10.0
0.10
√
F418
AI1 channel 0Hz voltage dead zone
0
～0.50V (Positive-Negative)
0.00
√
F419
AI2 channel 0Hz voltage dead zone
0
～0.50V (Positive-Negative)
0.00
√
F421
Panel selection
0: Local keypad panel
1: Remote control keypad panel
2: Local keypad + remote control
keypad
1
√
F422
Reserved
