Parker AC10 series User Manual

15-12 Parameter Reference
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
1: valid
inverter
model
F632 Target voltage of VDC adjustor (V) 200-800
√
F633-
F649
Reserved
F650 High-frequency performance
0: Invalid
1: Terminal enabled
2: Enabled mode 1
3: Enabled mode 2
2
×〇
F651 Switchover frequency 1 F652-150.00 100.00
√〇
F652 Switchover frequency 2 0-F651 95.00
√〇
F653-
F670
Reserved
Timing Control and Protection: F700-F770
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F700
Selection of terminal free stop mode
0:
Free stop immediately;
1:
Delayed free stop
0
√
F701
D
elay time for free stop and programmable
terminal
action
0.0
～60.0s
0.0
√
F702
Fan control mode
0:
Controlled by temperature
1: Running when inverter is powered
on
2: Controlled by running status
2
√
F703
Reserved
F704
Inverter Overloading pre
-alarm Coefficient
(%)
50~100
80
╳
F705
Overloading
adjusting gains
50~100
80
╳
F706
Inverter Overloading
coefficient％
120
～190
150
╳
F707
Motor Overloading
coefficient ％
20
～100
100
╳
F708
Record of The Latest Malfunction Type
2: Over current (OC)
3: over voltage (OE)
4: input phase loss (PF1)
5: inverter overload (OL1)
6: under voltage (LU)
7: overheat (OH)
8: motor overload (OL2)
11: external malfunction (ESP)
13. studying parameters without motor
(Err2)
16: Over current 1 (OC1)
17: output phase loss (PF0)
18: Aerr analog disconnected
23: Err5 PID parameters are set
△
F709
Record of Malfunction Type for Last but One
△
F710
Record of Malfunction Type for Last but Two
△
