Parker AC10 series User Manual

15-14 Parameter Reference
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F742
Threshold of Analog Disconnected
Protection (%)
1~100 50
○
F745 Threshold of Pre-alarm Overheat (%) 0~100 80
○*
F747 Carrier Frequency Auto-adjusting 0: Invalid 1: Valid 1 √
F754 Zero-current Threshold (%) 0~200 5
╳
F755 Duration time of zero-current 0~60 0.5 √
Motor parameters: F800-F830
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F800 Motor’s Parameters Selection
Setting range:
0: Invalid;
1: Rotating tuning;
2: Stationary tuning
0
╳
F801 Rated Power
0.2～1000kW ○╳
F802 Rated Voltage 1～440V ○╳
F803 Rated Current
0.1～6500A ○╳
F804 Number of Motor Poles
2～100
4
○△
F805 Rated Rotary Speed
1～30000 ○╳
F806 Stator Resistance 0.001～65.00Ω ○╳
F807 Rotor Resistance
0.001～65.00Ω ○╳
F808 Leakage Inductance
0.01～650.0mH ○╳
F809 Mutual Inductance
0.1～6500mH ○╳
F810 Motor Rated Power 1.00~300.0Hz 50.00 ○╳
F812 Pre-exciting Time
0.000～3.000S
0.30 √
F813 Rotary Speed Loop KP1
0.01～20.00
Subject to
inverter
model
○√
F814 Rotary Speed Loop KI1
0.01～2.00
Subject to
inverter
model
○√
F815 Rotary Speed Loop KP2
0.01～20.00
Subject to
inverter
model
○√
F816 Rotary Speed Loop KI2
0.01～2.00
Subject to
inverter
model
○√
F817 PID Switching Frequency 1 0~F111 5.00 √
F818 PID Switching Frequency 2 F817~F111 50.00 √
F819~
F860
Reserved
Subject to
inverter
model
√
