Planning wireless systems
105542_en_05 PHOENIX CONTACT 139 / 198
8.10 Free space attenuation
When using wireless transmission technology, the signal between the transmitter and
receiver is attenuated by the air. The following table lists attenuation values for different dis-
tances with a free Fresnel zone.
Table 8-6 Free space attenuation
Distance Attenuation at 2.4 GHz Attenuation at 868 MHz
5m -54dB ...
10 m -60 dB ...
20 m -66 dB ...
30 m -69.5 dB ...
50 m -74 dB ...
100 m -80 dB -71.2 dB
110 m -80.8 dB ...
120 m -81.6 dB ...
150 m -83.5 dB ...
200 m -86 dB -77.2 dB
250 m -88 dB ...
300 m -89.5 dB -80.7 dB
350 m -90.9 dB ...
400 m -92 dB -83.2 dB
450 m -93.1 dB ...
500 m -94 dB -85.1 dB
550 m -94.8 dB ...
600 m -95.6 dB -86.7 dB
650 m -96.3 dB ...
700 m -96.9 dB -88.1 dB
750 m -97.5 dB ...
800 m -98.1 dB -89.2 dB
850 m -98.6 dB ...
900 m -99.1 dB -90.3 dB
950 m -99.6 dB ...
1000 m -100 dB -91.2 dB
2000 m - -97.2 dB
3000 m - -100.7 dB
4000 m - -103.2 dB
5000 m - -105.1 dB
6000 m - -106.7 dB
7000 m - -108.1 dB
8000 m - -109.2 dB
