4.5.2 Reading the memory stick
Reading common network parameters via the memory stick
• Insert the memory stick in the S-PORT of the wireless module.
• Press and hold down the SET button on the wireless module for at least one second.
Parameter read-in is started. Read-in has been completed when the DAT LED lights up
once. The new parameters are activated.
• Remove the memory stick from the wireless module.
Reading common network parameters and individual device parameters via the
memory stick
This function enables all common network parameters and individual device parameters to
be read into the wireless module. A full copy of devices can be created, e.g., as a backup
copy.
• Insert the memory stick in the S-PORT of the wireless module.
• Press and hold down the SET button on the wireless module for at least six seconds.
Parameter read-in is started, the DAT LED flashes.
• The read-in process has been completed once the DAT LED stops flashing. The new
parameters are activated.
• Remove the memory stick from the wireless module.
4.6 Configuration via the PSI-CONF software
You can make special settings using the PSI-CONF configuration and diagnostic software.
The software can be downloaded at phoenixcontact.net/products. A PC with Windows
operating system is required in order to use the software. Use the RAD-CABLE-USB cable
(Order No. 2903447) for configuration and diagnostics.
• Install the software and the USB driver for the RAD-CABLE-USB cable. Follow the soft-
ware wizard.
WARNING: Explosion hazard when used in potentially explosive areas
The USB cable must not be used in potentially explosive areas.
For additional information on the USB cable, please refer to the PACKB.RAD-CABLE-
USB packing slip. The latest documentation can be downloaded via the product at
phoenixcontact.net/product/2903447
.
