Omnidirectional antenna with protection against vandalism, 3 dBi
Figure A-2 Omnidirectional antenna with protection against vandalism, 3 dBi
RAD-2400-IFS
RAD-ID
Reset
+24 V
0 V
RSSI- RSSI+
ANT
SPORT
0 2
Pwr
Dat
Err
RX TX
D(A) D(B)
GND
RX
CO
1
NC
1
CO
2
TX
1
Item Product Description Connection Order No.
1 RAD-ISM-2400-ANT-VAN-3-0-
RSMA
Omnidirectional antenna with protection
against vandalism, 2.4 GHz, 3 dBi gain, IP55
protection, 1.5 m cable length, h/v 360°/85°
opening angle
Appropriate mounting material is available for
wall mounting.
RSMA (male) 2701358
