Technical data for the wireless modules
105542_en_05 PHOENIX CONTACT 159 / 198
10 Technical data for the wireless modules
Accessories
Description Ty pe Order No. Pcs./Pkt.
Wireless transceiver with RS-232/485 interface, can be
extended with I/O modules, RSMA (female) antenna con-
nection, point-to-point, star, and mesh networks
2.4 GHz, up to 250 stations, up to 5 km, worldwide use
868 MHz, up to 99 stations, up to 20 km, use in Europe
2.4 GHz, up to 250 stations, up to 5 km, use in Japan
RAD-2400-IFS
RAD-868-IFS
RAD-2400-IFS-JP
2901541
2904909
2702863
1
1
1
RS-485 front module Ty pe Order No. Pcs./Pkt.
RS-485 multipoint multiplexer, can be extended with
I/O modules, can be used as Modbus/RTU bus coupler or
can be combined with Radioline wireless system, up to
99 stations, range of up to 1.2 km on in-house copper ca-
bles
RAD-RS485-IFS 2702184 1
Extension modules Ty p e Order No. Pcs./Pkt.
I/O extension module, 4 analog current inputs
(0/4 mA...20 mA)
RAD-AI4-IFS 2901537 1
I/O extension module, 4 Pt100 inputs
(-50°C ... +250°C)
RAD-PT100-4-IFS 2904035 1
I/O extension module, 4 analog current or voltage outputs
(0/4mA...20mA, 0V...10V)
RAD-AO4-IFS 2901538 1
I/O extension module, 4 digital inputs (0 ... 250 V AC/DC) RAD-DI4-IFS 2901535 1
I/O extension module, 8 digital inputs (0 ... 30.5 V DC) or
2 pulse inputs up to 100 Hz
RAD-DI8-IFS 2901539 1
I/O extension module, 4 digital relay outputs
(5 A, 250 V AC / 24 V DC)
RAD-DOR4-IFS 2901536 1
I/O extension module, 8 digital transistor outputs
(30.5 V DC / 200 mA)
RAD-DO8-IFS 2902811 1
I/O extension module, 2 digital inputs and outputs
(0 ... 250 V AC/DC) and 1 analog input (0/4 ... 20 mA) and
output (0/4 ... 20 mA, 0 ... 10 V)
RAD-DAIO6-IFS 2901533 1
