Version 125
- Remove the 4 screws and the housing.
- To remove the intake throat on the transmission cover, just remove the 2 fixing screws indicated in
the figure.
Air duct filter
To remove the intake throat on the transmission
cover, remove the 2 fixing screws indicated in the
figure.
Carnaby 125 - 200 Engine
ENG - 101
