- Remove the minimum flow set screw and the
spring.
CAUTION
DO NOT ATTEMPT REMOVING PARTS EMBEDDED IN THE
CARBURETTOR BODY SUCH AS: FUEL SUPPLY PIPE,
PLUNGER HOUSING, STARTER NOZZLE, PIT COVER FOR
PROGRESSIONS AND INLET NOZZLE, MINIMUM AND
MAXIMUM AIR GAUGE, THROTTLE VALVE CONTROL
SHAFT. DO NOT REMOVE THROTTLE-SHAFT CONNEC-
TION SCREWS. THE FIXING SCREWS ARE CAULKED AF-
TER ASSEMBLY AND THEIR REMOVAL DAMAGES THE
SHAFT.
Refitting the carburettor
Kehin
- The screw final position should be determined by
an exhaust fume analysis.
- Adjust the carburettor by turning the screw twice
from the close position.
Carnaby 125 - 200 Engine
ENG - 181
