Front handlebar cover
- Operating on both sides of the scooter, remove
the two inspection covers of the brake calliper res-
ervoir «A».
- Undo the two screws «B».
- Remove the five screws «C».
- Remove the right and left controls assembly.
- Undo the two screws «D» and remove the front
handlebar cover.
CAUTION
OPERATE VERY CAREFULLY TO AVOID DAMAGING THE
PLASTIC PARTS
Chassis Carnaby 125 - 200
CHAS - 242
