PIAGGIO Carnaby 200 - Brakes

Specification Desc./Quantity
Spark plug CHAMPION RG4HC
Alternative spark plug NGK CR8EB
Battery Sealed, 12 V / 10 Ah
ELECTRICAL SYSTEM 200
Specification Desc./Quantity
Start-up Electric
Ignition Capacitive discharge ignition, with variable advance and sep-
arate HV coil.
Ignition advance 10° at 2,000 rpm - 26° at 6,750 rpm
Spark plug CHAMPION RG4HC
Alternative spark plug NGK CR8EB
Battery SEALED 12V / 12Ah BATTERY
Frame and suspensions
CHASSIS AND SUSPENSIONS
Specification Desc./Quantity
Chassis Tubular and sheet steel.
Front suspension Hydraulic telescopic fork with Ø 35-mm stem
Front suspension travel 104 mm
Rear suspension Two double-acting shock absorbers with preloading adjust-
ment in 4 positions.
Rear suspension travel - mm
Brakes
BRAKES
Specification
Desc./Quantity
Front brake Ø 260-mm disc brake with hydraulic control activated by han-
dlebar right lever.
Rear brake Ø 260-mm disc brake with hydraulic control activated by han-
dlebar left lever.
Wheels and tyres
WHEELS AND TYRES
Specification
Desc./Quantity
Wheel rim type Light alloy rims.
Front rim 16'' x 3.00
Rear rim 16'' x 3.00
Front tyre Tubeless, 110/70 - 16'' 52P
Rear tyre Tubeless, 130/70 - 16'' 61P
Front tyre pressure (with passenger) 2 bar (2 bar)
Rear tyre pressure (with passenger) 2.2 bar (2.3 bar)
N.B.
CHECK AND ADJUST TYRE PRESSURE WITH TYRES AT AMBIENT TEMPERATURE. REGU-
LATE PRESSURE ACCORDING TO THE WEIGHT OF THE RIDER AND ACCESSORIES
Secondary air
The SAS for LEADER engines operates in a similar manner to the SAS for 2T engines.
The differences are the following:
Carnaby 125 - 200 Characteristics
CHAR - 11
