Removing the driving pulley
- Preassemble the movable half-pulley with the
roller contrast plate by putting the rollers in their
housings with the larger support surface touching
the pulley according to the direction of rotation. -
Make sure the roller contact plate is not flawed or
damaged on the grooved edge. - Fit the unit to-
gether with the bushing on the crankshaft - Fit the
driven pulley/Clutch/belt unit on the engine.
- Remove the belt and slide the movable half-pul-
ley with the relevant bush, taking care of the falling
free assembled rollers.
- Remove the return rollers plate with the relative
guide pads.
Engine Carnaby 125 - 200
ENG - 116
