PIAGGIO Carnaby 200 - Headlight Assy.

Headlight assy.
- Undo the four screws «A» and remove the front
case «B».
- Undo the screw «C» and remove the cover to
reach the expansion tank cap.
- Operating on both sides of the scooter, undo the
eight screws «D».
Carnaby 125 - 200 Chassis
CHAS - 243
