Transmission cover
TRANSMISSION COVER
Code
Action Duration
1 001135 Transmission cover bearing - Re-
placement
2 001096 Transmission crankcase cover - re-
place
3 001131 Transmission air intake - Replace-
ment
Flywheel magneto
MAGNETO FLYWHEEL AND SECONDARY AIR
Code
Action Duration
1 001087 Flywheel cover - Replacement
2 001113 Water pump - Replacement
3 001058 Flywheel - Replacement
4 001173 Rotor - Replacement
5 001067 Stator - Replacement
Time Carnaby 125 - 200
TIME - 274
