Removal
- Remove the front wheel.
- Remove the handlebar.
- Using the appropriate tool, loosen and remove
the upper ring nut, the distancing washer, the
counter ring nut and the spacer ring.
- Extract the fork.
N.B.
TAKE CARE TO SUPPORT THE FORK SO AS TO PREVENT
IT FROM COMING OFF ABRUPTLY
Specific tooling
020055Y Wrench for steering tube ring nut
See also
Removal
Removing the front wheel
Overhaul
- With the 10 mm hexagonal wrench for internal
parts loosen the upper stem closing cap.
- Loosen the stem support clamp and remove fork
leg and stem.
Carnaby 125 - 200 Suspensions
SUSP - 197
