SERVICE STATION
MANUAL
Carnaby 125 - 200
The descriptions and illustrations given in this publication are not binding. While the basic specifications
as described and illustrated in this manual remain unchanged, PIAGGIO-GILERA reserves the right, at
any time and without being required to update this publication beforehand, to make any changes to
components, parts or accessories, which it considers necessary to improve the product or which are
required for manufacturing or construction reasons.
Not all versions/models shown in this publication are available in all countries. The availability of single
versions should be checked at the official Piaggio sales network.
"© Copyright 2007 - PIAGGIO & C. S.p.A. Pontedera. All rights reserved. Reproduction of this publication
in whole or in part is prohibited."
PIAGGIO & C. S.p.A. - After-Sales
V.le Rinaldo Piaggio, 23 - 56025 PONTEDERA (Pi)

PIAGGIO Carnaby 200 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	198 cc
Fuel System	Carburetor
Cooling	Liquid cooled
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Weight	146 kg
Max Torque	17 Nm
Transmission	CVT
Rear Suspension	Two hydraulic shock absorbers with adjustable preload
Fuel Tank Capacity	7.5 liters
