Raymarine e127 User Manual

9.6Databaranddataboxoverview
Youcancustomizethedatadisplayedinthedatabar
andonscreendataboxes.
Customizabledataisdisplayedinthedatabar,
extendeddatabar(HybridTouchdisplaysonly)or
databoxes.Thedatabar,extendeddatabarand
databoxesareavailableinallapplications.
Theseareasofthescreenareillustratedand
describedbelow:
D12296-3
2 3
5
1
4
1.Databar—displayedatthetopofthescreenin
allapplications.Thedatabarcontainscellsthat
canbecustomizedtodisplaydatafromawide
rangeofcategories.Thedatabarcanalsobe
hiddentoprovide
2.ExpandedDatabar—(Touchscreendisplays
only)displayedwhenyoutouchthedatabar.
Theextendeddatabarcanbedisplayed.The
expandeddatabarisdisplayeduntilthescreen
istouchedagain.
3.Statusicons—Youcandisplaythestatusicons
belowtheexpandeddatabar.Thisprovides
statusinformationforexternallyconnected
equipment:
4.StatusBar—Permanentlydisplayedinall
applications.Thestatusbarcontainsinformation
onthecurrentlyselectedsettingsofthe
applicationdisplayedonscreen.
5.Databoxes—upto2databoxescanbe
displayed.Eachboxcandisplayoneitemof
datafromtheavailabledatacategories.Datais
permanentlydisplayedonscreen.
Thedatabarcanbesettoauto-hidesothatonlythe
Statusbarisvisibleonscreen.
Auto-hidethedatabar
Onmultifunctiondisplaysthathaveatouchscreen,
thedatabarthatisdisplayedatthetopofall
applicationspagescanbesettoauto-hide.This
providesalargerscreenareafortheapplication
pages.
D13003-1
1 2
FromtheHomescreen:
1.SelectCustomize.
2.SelectDatabarSet-up.
3.SelectAuto-HidesothatOnisselected.
Whenviewingapplicationpagesthedatabarwill
nowauto-hideafter10seconds.Youcanviewthe
databaragainbytouchingthedatabarwithyour
nger.
Customizingdataboxesinthechart
application
Toswitchdataboxesonandoffandtoselectdatato
displayfollowthestepsbelow.
FromtheChartapplicationmenu:
1.SelectPresentation.
2.SelectOverlay.
3.SelectDataboxes.
4.SelectDatabox1>On.
5.SelectDatabox2>On.
6.ChoosetheSelectDataoptionfortherelevant
databox.
7.Selectthecategorythatreectsthetypeofdata
youwanttodisplayinthedatabox.Forexample,
Depthdata.
8.Selectthedataitem.
Thedatayouselectedisdisplayedonscreenin
theappropriatedatabox.
CustomizingDataboxes
IntheRadar,Fishnder,orWeatherapplication:
1.SelectMenu.
2.SelectPresentation.
3.SelectDataboxes.
4.SelectDatabox1>ON.
5.SelectDatabox2>ON.
6.ChoosetheSelectDatabox1orSelectDatabox
2menuitem,asappropriate.
7.Selectthecategorythatreectsthetypeofdata
youwanttodisplayinthedatabox.Forexample,
Depthdata.
8.Selectthedataitem.
Thedatayouselectedisdisplayedonscreenin
theappropriatedatabox.
Customizingyourdisplay
137

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
