3.6Typicalsystems
Theillustrationsbelowshowexamplesofpossiblesystemcongurations,formoredetailsoncompatible
RaymarinedevicespleaserefertotheSystemintegrationsection.
Note:Intheexamplesbelowthemultifunctiondisplay(s)couldbeanyvariantofRaymarine’s3rd
generationmultifunctiondisplayse.g.aSeries,cSeries,eSeriesorgSSeries.
Example:Basicsystem
SeaTalk
ng
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
6
00
D12245-3
1
2
3 4 5
1.Multifunctiondisplay
2.Networkswitch
3.Radarscanner
4.ActuatorControlUnit(ACU)
5.Evolutionautopilot
6.SeaTalk
ng
pilotcontroller(optional)
Note:AnetworkswitchisonlyrequiredifmultipledevicesareconnectedusingSeaTalk
hs
/RayNet.
Example:Basicsystemwithsonarvariantdisplay
SeaTalk
ng
SeaTalk
hs
/ RayNet
00
D12589-2
1 2 3 4 5
1.Multifunctiondisplay
2.Sonartransducer
3.Radarscanner
4.Evolutionautopilot
5.SeaTalk
ng
pilotcontroller(optional)
Planningtheinstallation
39

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
