23.1Thermalcameraapplication
overview
Thethermalcameraapplicationenablesyouto
controlaconnectedthermalcameraanddisplayits
imageonyourmultifunctiondisplay.
Thermalimaging(alsoknownasinfrared)cameras
enableyoutoseeclearlyinlow-lightandno-light
conditions.Forexample,athermalcameracanhelp
younavigateatnightoridentifyobstaclesinareasof
lowvisibilityoreventotaldarkness.
Thethermalapplicationenablesyouto:
•Controlthecamera:
–Pan.
–Tilt.
–Zoom(range).
–Returncamerato“home”(default)position.
–Setthecamera“home”position.
–Pausethecameraimage.
–Togglebetweenvisiblelightandthermalcamera
lenses.
–Togglesurveillancemode.
•Adjustthecameraimage:
–Colorpalette.
–Scenepresets.
–Brightness.
–Contrast.
–Color.
–Videopolarity(reversevideocolor).
Displayingthethermalcameraapplication
Withthehomescreendisplayed:
1.Selectapageiconthatincludesthethermal
cameraapplication.
Thethermalcameraapplicationisdisplayed.
Note:IfthehomescreendoesNOTinclude
apageiconthatfeaturesthethermalcamera
applicationyouwillneedtocreateanewpageicon
featuringthethermalcameraapplication.
23.2Thermalcameraimage
Thethermalcameraprovidesavideoimagewhich
isshownonyourdisplay.
Thevideofeedprovides:
•Thermalimage.
•Statusicons/systeminformation.
Youshouldtaketimetofamiliarizeyourselfwiththe
thermalimage.Thiswillhelpyoutomakethemost
ofyoursystem:
•Considereveryobjectyouviewintermsofhowit
willlook“thermally”asopposedtohowitlooksto
youreye.Forexamplelookforchangescausedby
theheatingeffectofthesun.Theseareparticularly
evidentrightaftersunset.
•Experimentwithwhite-hotandblack-hot(reverse
video)modes.
•Experimentbylookingforhotobjects(suchas
people)comparedtothecoldersurroundings.
•Experimentwiththecamerafordaytimeviewing.
Thecameracanprovideimproveddaytime
viewinginenvironmentswheretraditionalvideo
cameraperformancesuffers,suchasinshadows
orbacklitscenes.
Thermalcamerastatusicons
Thethermalcameraimageincludesiconstoshow
thecurrentstatusofthecamera.
IconDescription
Cameradirectionindicator.
Camerahomeposition.
Camerapaused.
Scenepresetmodefornightconditions.
Scenepresetmodefordaytime
conditions.
352aSeries/cSeries/eSeries

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
