19.6Customchannels
WhenconnectedtoanExternalTraditionalsonar
modulesuchastheCP300oranExternalCHIRP
sonarmodulesuchastheCP450C,customchannels
canbecreatedfromthesonarmodule’sdefault
channels;excludingAutochannels.Thisenables
somesettingstobecustomizedandsavedasa
separatechannel.Thesechannelscanthenbe
assignedtoindividualFishnderapplicationpanes.
Upto10customchannelscanbecreatedforeach
compatiblesonarmodule.
Whenchangedthefollowingsettingsaresavedto
thechannelthatiscurrentlydisplayed:
•Sensitivitysettings
•Rangesettings
•Frequencytuning—Only2frequencysettings
canbesavedpertransducer/sonarmodule
combination.
Note:PerformingaSonarResetwilleraseall
customchannelsforthecurrentsonarmodule.
Creatingacustomchannel
Tocreateacustomchannelfollowthestepsbelow.
FromtheFishnderapplicationmenu:
1.SelectChannel.
TheChannelselectionpageisdisplayed.
2.Selectthetabforthesonarmoduleyouwantto
createacustomchannelfor.
3.SelecttheChanneloptionsiconlocatednextto
thechannelthatyouwanttouse,or
4.usingnon–touchcontrols,selectthechannel
andthenpressandholdtheOkbuttonuntilthe
optionsscreenisdisplayed.
5.SelectCopyChannel.
Theon-screenkeyboardisdisplayed.
6.Enterthenameyouwanttoassigntoyournew
channel.
7.SelectSAVE.
Thenewchannelisnowavailableinthechannel
listfortherelevantsonarmodule.
8.Selectthenewchanneltodisplayitinthe
Fishnderapplicationpane.
ChangesmadetotheSensitivity,Rangeor
Frequencytuningsettingsareautomatically
savedtothechanneldisplayed.
YoucannowassignthenewchanneltoaFishnder
applicationpane.
Renamingcustomchannels
WiththeChannelselectionpagedisplayed:
1.Selectthetabforthesonarmodulethatcontains
thechannelyouwanttorename.
2.SelecttheChanneloptionsiconnexttothe
customchannel.
Thecustomchanneloptionspageisdisplayed
3.SelectRename.
Theon-screenkeyboardisdisplayed.
4.Enterthenewnameforthechannel.
5.SelectSAVE.
Deletingcustomchannels
WiththeChannelselectionpagedisplayed:
1.Selectthetabforthesonarmodulethatcontains
thechannelyouwanttodelete.
2.SelecttheChanneloptionsiconnexttothe
customchannel.
3.SelectDelete.
Aconrmationdialogisdisplayed.
4.SelectYes.
Thecustomchannelhasnowbeenremovedfrom
yoursystem.
Fishnderapplication
271

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
