Note:Themaximumlengthfortheradarpower
anddatadigitalcable(includinganyextensions)
is25m(82ft).
4.9Sonarconnection
Asonarconnectionisrequiredtoenableuseofthe
Fishnderapplication.
TheMFDcanbeusedwiththefollowingRaymarine
sonarmodules:
•CP450C
•CP300
•CP200
•CP100
Thereare2typesofconnectionrequiredfor
Fishnderapplications:
•Sonarmoduleconnection—convertsthesonar
signalsprovidedbythesonartransducerinto
datasuitableforamarineelectronicssystem.
Thesonarvariantmultifunctiondisplaysfeature
abuilt-insonar,enablingyoutoconnectthe
displaydirectlytoacompatiblesonartransducer.
Non-sonarvariantsrequireaconnectiontoan
externalRaymarinesonarmodule.Internal
andexternalsonarsrequireaconnectiontoa
compatiblesonartransducer.
•Sonartransducerconnection—providessonar
signalstothesonarmodule.
Sonarmoduleconnection
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
D12255-1
1
2
3
4
1.Rearconnectorpanelofmultifunctiondisplay
(Non-sonarvariant).
2.Raymarinenetworkswitch.
3.Raymarinesonarmodule.
4.RayNetcable.
Ifasparenetworkconnectionisavailableonyour
multifunctiondisplaythenasonarmodulemaybe
connecteddirectlytothedisplay,withoutusinga
Raymarinenetworkswitch.
Note:YoucanalsoconnectasonarvariantMFD
toaRaymarine
®
sonarmodule.Thisisusefulin
circumstanceswhereyouneedahigherpowered
sonarmoduleforexample.
Multipleactivesonarmodules
Multipleactivesonarmodulescanbepresentonthe
samenetwork,youmustselectwhichsonarmodule/
channelyouwanttouseintheFishnderapplication.
60aSeries/cSeries/eSeries

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
