19.17Fishnderalarms
ThefollowingFishnderalarmscanbesetwhena
depthdatasourceisavailable.
•Fish—alarmsoundswhenatargetmeetsthe
speciedsensitivityleveland,iswithinthedepth
limits(ifenabled).
•FishnderDeep—alarmsoundswhenthe
detecteddepthisgreaterthanthedeeplimit.
•FishnderShallow—alarmsoundswhenthe
detecteddepthislessthantheshallowlimit.
Settingupshalarms
FromtheAlarmsmenuhomescreen>Set-up>
Alarms:
1.SelectFish.
TheFishalarmsmenuisdisplayed.
2.SelectFishsothatOnishighlighted.
3.SelectFishSensitivity.
Theshsensitivitynumericadjustcontrolis
displayed.
4.Adjusttheshsensitivitytotherequirevalue.
Thegreatertheshalarmsensitivity,thegreater
thenumberoftargetimagedepthsdisplayed.
5.SelectFishDepthLimitssothatOnis
highlighted.
Theshallowanddeepshlimitsettingswillbe
activatedinthemenu.
6.SelectShallowFishLimit.
Theshallowshlimitnumericadjustcontrolis
displayed.
7.Adjustthevaluetotherequiresetting.
8.SelectOktoconrmthenewvalueandclosethe
numericadjustcontrol.
9.SelectDeepFishLimit.
Thedeepshlimitnumericadjustcontrolis
displayed.
10.Adjustthevaluetotherequiresetting.
11.SelectOktoconrmthenewvalueandclosethe
numericadjustcontrol.
Settingupshnderdeepalarm
FromtheAlarmsmenuhomescreen>Set-up>
Alarms:
1.SelectFishnderDeep.
2.SelectDeepsothatOnishighlighted.
SelectingDeepwillswitchbetweenOnandOff.
3.SelectDeepLimit.
Thedeeplimitnumericadjustcontrolisdisplayed.
4.Adjustthesettingtotherequiredvalue.
5.SelectOktoconrmthenewvalueandclosethe
numericadjustcontrol.
Note:TheDeepLimitcannotbesettolessthan
theShallowLimit.
Settingupshndershallowalarm
FromtheAlarmsmenuhomescreen>Set-up>
Alarms:
1.SelectFishnderShallow.
2.SelectShallowsothatOnishighlighted.
SelectingShallowwillswitchbetweenOnandOff.
3.SelectShallowLimit.
Theshallowlimitnumericadjustcontrolis
displayed.
4.Adjustthesettingtotherequiredvalue.
5.SelectOktoconrmthenewvalueandclosethe
numericadjustcontrol.
Note:TheShallowLimitcannotbesettogreater
thantheDeepLimit.
Fishnderapplication
285

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
