18.7ChartOrientation
Theorientationofachartreferstotherelationship
betweenthechartandthedirectionthatyouare
travellingin.
ChartOrientationisusedinconjunctionwithMotion
Modetocontrolhowyourvesselandchartrelateto
oneanotherandhowtheyaredisplayedon-screen.
ThemodeyouchooseappliestotheactiveChart
instance,andisrestoredatpowerup.
Thefollowingoptionsareavailable:
NorthUp
N
D12300-2
InNorthUpmode,theChartOrientationis
xedwithtruenorthpointingupthisisthe(usual
orientationofnauticalcharts).Asyourheading
changesthevesselsymbolrotatesaccordingly.This
isthedefaultorientationfortheChartapplication.
HeadUp
N
D12298-2
InHeadUpmode,theChartapplicationdisplaysthe
vessel’scurrentHeadingdirectlyup.Asthevessel
Headingchangesthevesselsymbolremainsxed
andthechartpicturerotatesaccordingly.IfHeading
isnotavailablethenstableCOGisusedinstead.If
HeadingorstableCOGdataisnolongerpresent
thentheOrientationmodeissuspendedandthe
Chartapplicationwilldisplay0degreesdirectlyup
ifthereisnoactivenavigationorCourseUpifthere
isactivenavigation.
Note:Topreventcontinuousbackwardsand
forwardsrotationsasthevesselyawsfrom
side-to-side,thechartwillnotupdateunlessthe
headingchangesbyatleast10degreesfromthe
lastdisplayedorientation.
Note:ItisnotpossibletoselectHead-Upwhen
theMotionModeissettoTrue.
CourseUp
N
D12299-2
InCourseUpmode,duringactivenavigation,
theChartapplicationdisplaysthevessel’scurrent
destinationwaypointdirectlyup.Whenthe
destinationwaypointchangesthechartpicture
rotatesaccordingly.ThereferenceusedforCourse
Updependsupontheinformationavailableatagiven
time.Thesystemalwaysprioritizesthisinformation
inthefollowingorder:
1.BearingOrigintowaypoint
2.LockedheadingfromanAutopilot
3.BTW(BearingToWaypoint)
4.Headingsnapshot
5.StableCOG
6.NorthUp
IfHeadingorstableCOGdataisnolongerpresent
thentheOrientationmodeissuspendedandthe
Chartapplicationwilldisplay0degreesdirectlyup
ifthereisnoactivenavigationorCourseUpifthere
isactivenavigation.
Settingthechartorientation
FromtheChartapplicationmenu:
1.SelectPresentation.
2.SelectView&Motion.
3.SelectChartOrientation.
4.SelectHeadUp,NorthUp(default),orCourse
Upoptionasappropriate.
Onceselectedthescreenwillupdatetoreect
theneworientation.
Chartapplication
239

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
