Raymarine e127 User Manual

4.14GPSconnection
Dependingondisplayvariant,yourmultifunction
displaymayincludeaninternalGPSreceiver.If
requiredthemultifunctiondisplaycanalsobe
connectedtoanexternalGPSreceiver,using
SeaTalk
ng
orNMEA0183.
GPSconnection—SeaTalk
ng
D12261-1
SeaTalk
ng
1
2
1.Multifunctiondisplay.
2.SeaTalk
ng
GPSreceiver.
GPSconnection—NMEA0183
D12262-1
NMEA 0183
1 2
1.Multifunctiondisplay.
2.NMEA0183GPSreceiver.
4.15GA150connection
a9xanda12xMFDsincludeaninternalGNSS(GPS
/GLONASS)receiver.TheGA150antennacan
beusedtoimprovetheGNSS(GPS/GLONASS)
receiver’sreception.
D13069-1
21
1.GA150antenna
2.a9xora12xvariantMFD
Forinstallationdetailsforyourexternalantenna,
refertothedocumentationthataccompaniedthe
antenna.
Note:
•TheBeidouGNSSissupportedbutnotcurrently
available.
•AGA150mustbeconnectedinordertoreceive
theBeidousystemwhenitbecomesavailable.
•Asoftwareupdatewillberequiredtoadd
supportforBeidouoncethesystemisavailable.
PleasecheckwithyourRaymarinedealerfor
furtherdetails.
Antennacablelength
TheGA150issuppliedwithatted10m(33ft.)
cable.Thelengthoftheantennacablecanbe
extendedifrequired.
Theantennacablelengthcanbeextendedbyupto
10m(33ft.)givingatotalmaximumcablelength
of20m(66ft.)
50ohmcoaxialcableandreliableconnectors
(offeringprotectionagainstwateringress)mustbe
usedwhenextendingtheantennacable.
Note:Extendingthecablelengthbymorethan
therecommendedmaximumlengthwillresultin
signaldegradation.
Connectinganexternalantenna
FollowthestepsbelowtoconnecttheGA150
externalantennatoyoura9xora12xvariantMFD.
Cablesandconnections67

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
