Raymarine e127 User Manual

16.8AIStargetsymbols
Yourmultifunctiondisplayshowsarangeofsymbols
torepresentthedifferenttypesofAIStarget.
TargettypeDescriptionSymbol
TransmittingtargetTargetismovingor
atanchor(Target
isnotactivated,
dangerousorlost).
ActivatedtargetTargetactivated—
thatis,AISvector
displayed.Vector
line(optional)
showspredicted
distancetravelled
withinagiventime.
Selectedtarget
Targetselected
withcursor.Can
viewdetaileddata.
DangeroustargetTargetswithin
specieddistance
(CPA)or
time(TCPA).
Dangeroustarget
alarmsoundsif
enabled.Target
redandashing.
Uncertaintarget
CalculatedCPA
/TCPAvalue
uncertain.
Losttarget
Whenthesignalof
adangeroustarget
notreceivedfor20
seconds.Target
inlatestpredicted
position.Alarms
soundsifenabled.
Targetashes.
BuddytargetTargethas
previouslybeen
addedtothe
BuddyList.
AidToNavigation
(AToN)target
(Real)
AToNtargetisON
position.
AidToNavigation
(AToN)target
(Real)
AToNtargetisOFF
position.
AidToNavigation
(AToN)target
(Virtual)
AToNtargetisON
position.
AidToNavigation
(AToN)target
(Virtual)
AToNtargetisOFF
position.
Landbasestation
target
Landbasestation
targetisONLINE.
TargettypeDescriptionSymbol
Searchandrescue
transponders
(SARTS)target
SARTStarget
Searchandrescue
aircraft(SARS)
target
SARStarget
Militaryandlaw
enforcementtarget
Onlydisplayed
whenconnected
toapproved
STEDS-EAISAIS
hardware.
200aSeries/cSeries/eSeries

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
