Raymarine e127 User Manual

18.10Chartdisplay
TheChartDisplaymenuoptiondeterminesthelevel
ofdetailthatisdisplayedon-screen.
TheChartdisplaymenuoptionisonlyavailable
whenusingvectorbasedcartography.
TheChartdisplayoptionsareshownbelow.
Simple
Detailed
ExtraDetailed
Thelevelofdetailshownon-screenisalsoaffected
bythecartographyChartdetailsettings.Referto
Chartdetailforinformation.
Changingthechartdisplaydetail
FromtheChartapplicationmenu:
1.SelectPresentation.
2.SelectChartDetail.
Thefollowingoptionsareavailable:
•Simple
•Detailed
•ExtraDetailed
3.Selecttherequiredoption.
18.11Overlays
Thecharthasanumberofoverlaysthatdisplay
differentviewsandinformation.Theoverlaysrequire
electronicchartswiththeappropriatefeaturesupport
andmayalsorequireadditionalhardwareand
servicesubscriptions.
Youcanoverlaythefollowingdataontoa2Dchart
togivegreaterdepthofinformation.Theoverlays
availableare:
•*AIS—ViewandtrackAIStargets.Thisoverlay
isnotavailablein3Dview.
•*Radar—Overlayradarontothechart.This
overlayisnotavailablein3Dview.
•**Aerial—Providesanaerial/satellite
photographyoverlay.
•**AerialOverlay:—Determinesthecoverageof
theaerialoverlay.
•*NOWRad—ProvidestheNOWRadweather
radaroverlay.Thisoverlayisnotavailablein3D
view.
•Databoxes—Selectwhetherdataboxesare
displayedon-screenandwhatdataisdisplayed.
•ChartGrid—Determineswhethergridlines
representinglongitudeandlatitudearedisplayed
onthechart.
•**2DShading—Determineswhetherterrain
shadingisdisplayedin2Dview.
•**CommunityEdits—Determineswhetherthe
communitylayerisenabledordisabled.
•**ChartText—Determineswhethercharttextis
displayed(placenamesandsoon).
•ChartBoundaries—Determineswhetheraline
indicatingthechartboundaryisdisplayed.
•RangeRings—ViewrangeringsintheChart
application.Thisoverlayisnotavailablein3D
view.
•SafeZoneRing—Viewsafezonering.This
overlayisnotavailablein3Dview.
•FuelRangeRing—Viewthefuelrangering.This
overlayisnotavailablein3Dview.
•BoatSize—Determinesthesizeoftheboaticon
on-screen.
•WaypointName—Determineswhetherthe
Waypointnamesaredisplayednexttowaypoints.
•RouteWidth—Determinethewidthofroutelines
on-screen.
•TrackWidth—Determinethewidthoftracklines
on-screen.
Note:
*Additionalhardwarerequired.
**Ifsupportedbyyourcartographytype.
Chartapplication
243

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
