22.2Changingthecamerafeed
Changingthecamera/videofeed
OnaNewaSeriesorNeweSeriesdisplay,ifmore
than1feedisavailableyoucanchangewhichfeed
isdisplayedonthescreenusingtouch.
D12598-1
FromtheCameraapplication.
1.T ouchandswipeyourngeruptomovetothe
nextvideofeed.
2.T ouchandswipeyourngerdowntodisplaythe
previousvideofeed.
Changingthecamera/videofeed
OnaNewcSeriesorNeweSeriesdisplay,ifmore
than1feedisavailableyoucanchangewhichfeed
isdisplayedonthescreenusingtheJoystick.
FromtheCameraapplication
1.MovetheJoystickDowntodisplaythenext
videofeed.
2.MovetheJoystickUptodisplaytheprevious
videofeed.
Changingthecamera/videofeedusingthe
menu
Whenmorethan1feedisavailable,youcanchange
whichfeedisdisplayedonscreenusingthemenu.
FromtheCameraapplication:
1.SelectMenu.
2.SelectCameraView.
3.SelectCamera:.
4.Selectthefeedyouwanttodisplay.
22.3Displayingmultiplecamerafeeds
usingQuadView
WhenanIPcameraisavailableonthenetwork,the
CameraapplicationcanbesettoQuadView.In
QuadViewupto4camerafeedscanbeviewed
simultaneously.
QuadViewcanconsistofupto4xIPfeedsor1x
analogfeedandupto3xIPfeeds.
ToenableQuadView,fromtheCameraapplication:
1.SelectMenu.
2.SelectCameraView.
3.SelectLayout:sothatQuadViewisdisplayed.
4.Arrangethefeedsbyselectingafeedineach
oftheTop-Left,Top-Right,Bottom-Land
Bottom-Rmenuoptionsasrequired.
Analogfeedscanonlybedisplayedinthetop
leftcorner.
5.Thetopleftcornercanalsobesettocycle
throughallavailableanalogandIPfeedsusing
thecyclingoptionsavailableintheTop-Left
menu.
See22.4Cameracyclingfordetailsofcycling
feeds.
Recording,takingphotos,namingfeedsand
adjustingthevideoimagearenotsupportedinQuad
View;howeveritispossibletoswitchtoQuadView
whilstrecordinginSingleView.
Note:ExceptforgSSeriesdisplays,QuadView
isnotavailableonMFDswitha9inchorbelow
screensizewhentheCameraapplicationisbeing
viewedaspartofasplitscreenpage.
Note:DisplayingmultipleIPfeedsonmultiple
MFDssimultaneouslymaycausesomefeedsto
notbedisplayed.
Usingonscreencontrols
Ontouchscreendisplays,onscreencontrolsare
availabletoquicklyswitchbetweenQuadViewand
SingleView.
InQuadView:
1.Selectthefeed.
TheExpandicon
isdisplayed.
2.SelecttheExpandicontoviewthefeedin
fullscreen.
Cameraapplication
343

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
