33.2DownVision
TM
transducersand
accessories
Thetransducerslistedbelowcanbeconnected
directlytoDownVision
TM
variantMFDs.
Depthandtemperaturetransducers
PartnumberImageMountingHousing
A80270 Transom
CPT-100
plastic
A80277 Thru-hull
CPT-110
plastic
A80271 Thru-hull
CPT-120
bronze
PartnumberDescriptionNotes
A80207Transomtransducer
shieldforvesselswith
atrollingmotor
A80273
4m(13.12ft)
transducerextension
cableforCPT-100,
CPT-110and
CPT-120transducers
33.3Networkhardware
Item
Part
num-
berNotes
HS5RayNet
networkswitch
A80007
5–portswitchfornetwork
connectionofmultiple
devicesfeaturingRayNet
connectors.Equipmentwith
RJ45SeaTalk
hs
connectors
canalsobeconnectedusing
suitableadaptercables.
RJ45SeaTalk
hs
networkswitch
E55058
8–portswitchfornetwork
connectionofmultiple
SeaTalk
hs
devicesfeaturing
RJ45connectors.
RJ45SeaTalk
hs
crossovercoupler
E55060•Enablesdirectconnection
ofRJ45SeaTalk
hs
devices
tosmallersystemswhere
aswitchisnotrequired.
•Enablestheconnectionof
RJ45SeaTalk
hs
devices
toaHS5RayNetnetwork
switch(inconjunctionwith
suitableadaptercables).
•Enables2RJ45SeaTalk
hs
cablestobeconnected
togethertoextendthe
lengthofthecabling.
Recommendedforinternal
installations.
Important:DoNOTuse
crossoverdevicesforPOE
(PowerOverEthernet)
connections.
EthernetRJ45
coupler
R32142•Enablesdirectconnection
ofRJ45SeaTalk
hs
devices
tosmallersystemswhere
aswitchisnotrequired.
•Enablestheconnectionof
RJ45SeaTalk
hs
devices
toaHS5RayNetnetwork
switch(inconjunctionwith
suitableadaptercables).
•Enables2RJ45SeaTalk
hs
cablestobeconnected
togethertoextendthe
lengthofthecabling.
Recommendedforexternal
installations.
Sparesandaccessories
439
