Raymarine e127 User Manual

•Othersuitable12Vpowersupply.
Note:SeaTalk
ng
doesNOTsupplypowerto
multifunctiondisplaysandotherequipmentwitha
dedicatedpowersupplyinput.
4.19NMEA2000connection
ThedisplaycanreceivedatafromNMEA2000
devices(e.g.datafromcompatibleengines).The
NMEA2000connectionismadeusingSeaT alk
ng
andappropriateadaptorcables.
YoucanEITHER:
•UseyourSeaTalk
ng
backboneandconnecteach
NMEA2000deviceonaspur,OR
•connectthedisplayonaspurintoanexisting
NMEA2000backbone.
Important:Youcannothave2backbones
connectedtogether.
ConnectingNMEA2000equipmenttothe
SeaTalk
ng
backbone
NMEA 200012V
D12174-2
1
2
4
3
SeaTalk
ng
1.12Vsupplyintobackbone.
2.SeaTalk
ng
backbone.
3.SeaTalk
ng
toDeviceNetadaptorcable.
4.NMEA2000equipment.
ConnectingthedisplaytoanexistingNMEA2000
(DeviceNet)backbone
D12175-2
32
4
1
1.Multifunctiondisplay.
2.SeaTalk
ng
toDeviceNetadaptorcable.
3.DeviceNetbackbone.
4.NMEA2000equipment.
70aSeries/cSeries/eSeries

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
