5.2Mounting-cSeriesandeSeries
Removingtherearbezel
Youmustremovetherearbezelbeforesurface
mountingthedisplay.
Note:Thesestepsdonotapplytothee165asit
doesnotrequirearearbezel.
1.Removethefrontbezel.Refertotheseparate
instructionsprovidedforthatprocedure.
D12184-3
e7 / e7D
1
3
2
2.Removethescrewsthatsecurethebezeltothe
display(onlyrequiredfore7ande7D).
3.Carefullyremovethebezelfromtherearofthe
display,pullingthebezelgentlyalongthe:
i.Outeredges-workfromthesidesupwards
andthenalongthetopedge,ensuringthatthe
clipsarefullyreleasedfromthedisplay.
ii.Inneredges-ensurethatthebezelis
completelyremovedfromthedisplay.
Note:Onlythee7ande7Dhavexingscrewsfor
therearbezel,othermultifunctiondisplayvariants
haveclipswhichholdtherearbezelinplace.
Surfacemounting
Thedisplaycanbesurfacemounted.
Beforemountingtheunit,ensurethatyouhave:
•Selectedasuitablelocation.
•Identiedthecableconnectionsandroutethatthe
cableswilltake.
•Detachedthefrontbezel.
D12271-2
1.Checktheselectedlocationfortheunit.Aclear,
atareawithsuitableclearancebehindthepanel
isrequired.
2.Fixtheappropriatecuttingtemplatesupplied
withtheproduct,totheselectedlocation,using
maskingorself-adhesivetape.
3.Usingasuitableholesaw(thesizeisindicated
onthetemplate),makeaholeineachcornerof
thecut-outarea.
4.Usingasuitablesaw,cutalongtheinsideedge
ofthecut-outline.
5.Ensurethattheunittsintotheremovedarea
andthenlearoundtheroughedgeuntilsmooth.
6.Drill4holesasindicatedonthetemplateto
acceptthexings.
7.Placethegasketontothedisplayunitandpress
rmlyontotheange.
8.Connectthepower,dataandothercablestothe
unit.
9.Slidetheunitintoplaceandsecureusingthe
xingsprovided.
Note:Thesuppliedgasketprovidesaseal
betweentheunitandasuitablyatandstiff
mountingsurfaceorbinnacle.Thegasketshould
beusedinallinstallations.Itmayalsobe
necessarytouseamarine-gradesealantifthe
mountingsurfaceorbinnacleisnotentirelyatand
stifforhasaroughsurfacenish.
Attachingtherearbezel
Therearbezelmustbettedifyouwishtousea
mountingbrackettomounttheunit.
Note:Thesestepsdonotapplytothee165asit
doesnotrequirearearbezel.
1.Removethefrontbezel.Refertotheseparate
instructionsprovidedforthatprocedure.
2.Placethebezelovertherearofthedisplay,
ensuringthatitiscorrectlyalignedwiththe
display.Applyrmbutevenpressuretothebezel
alongthe:
84aSeries/cSeries/eSeries

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
