11.9PilotSet-up
WhenconnectedtoanEvolutionautopilotthePilot
Set-uppageisavailable.
D12883-1
9 10
4
6
7
5
8
21 3
1
Back—Gobacktothepreviousmenu.
2
PilotStatus—Currentpilotmode.
3
Close—Closesthepilotset-uppageanddisplays
thehomescreen.
4
Pilotcontrol—Switchesautopilotcontrolviathe
multifunctiondisplayonandoff.
5
Pilotbar—SwitchesthePilotbaronandoff.
6Pilotsettings—Displaysavailablepilotsettingsthat
canbeconguredfromthemultifunctiondisplay.
Note:ThePilotsettingsmenuisonlyavailableon
thedatamastermultifunctiondisplay.
7
Leisure—PlacestheautopilotinLeisuremode.
Leisuremodeissuitableforlongpassageswheretight
headingcontrolisnotcritical.
8
Performance—PlacestheautopilotinPerformance
mode.Performancemodeprovidesgoodcourse
keepingwithoutoverworkingtheautopilot.
9
Cruise—PlacestheautopilotinCruisemode.Cruise
modeprovidestightheadingcontrol.
10
Rudderbar—Indicatesthepositionoftherudder.
AccessingthePilotSet-uppage.
WhenconnectedtoanEvolutionautopilotyoucan
accessthePilotSet-uppagebyfollowingthesteps
below.
FromtheHomescreen:
1.SelectSet-up.
2.SelectSystemSettings.
3.SelectExternalDevices.
4.SelectPilotSet-up.
11.10Pilotsettings
ThePilotsettingsoptionisavailableonadata
mastermultifunctiondisplaywhenitisintegrated
withanEvolutionautopilot.
ThePilotsettingsenablethesetupand
commissioningofanEvolutionautopilotusinga
multifunctiondisplay.
ThePilotsettingsincludethefollowingoptions:
•VesselSettings
•DriveSettings
•SailBoatSettings
•Commissioning
Initialsetupandcommissioning
Vesselsettings
Thevesselsettingsaredesignedtoprovideoptimum
steeringperformancefortypicalvessels.
Itisimportanttocompletethevesselhulltype
selectionaspartoftheinitialset-up,asitformsa
keypartoftheautopilotcalibrationprocess.You
canalsoaccesstheoptionsatanytimebyselecting
PilotSettings>VesselsettingsfromthePilot
Set-uppage.
Vesselsettingincludethefollowingoptions:
•VesselHullType
•DriveType
•CompassOffset
•CalibrationLock
Vesselhulltypeselection
Thevesselhulltypeoptionsaredesignedtoprovide
optimumsteeringperformancefortypicalvessels.
Itisimportanttocompletethevesselhulltype
selectionaspartoftheinitialset-up,asitformsa
keypartofthecommissioningprocess.Youcan
alsoaccesstheoptionsatanytimewiththepilotin
StandbyfromthePilotSet-uppagebyselecting:
PilotSettings>VesselSettings>VesselHull
Type.
Asageneralguide,selecttheoptionthatmost
closelymatchesyourvesseltypeandsteering
characteristics.Theoptionsare:
•Sail.
•Sail(slowturn).
•SailCatamaran.
•Power
•Power(slowturn).
•Power(fastturn).
Itisimportanttobeawarethatsteeringforces(and
thereforerate-of-turn)varysignicantlydepending
onthecombinationofvesseltype,steeringsystem,
anddrivetype.Therefore,theavailablevesselhull
typeoptionsareprovidedforguidanceonly.You
maywishtoexperimentwiththedifferentvesselhull
typeoptions,asitmightbepossibletoimprovethe
steeringperformanceofyourvesselbyselectinga
differentvesseltype.
Autopilotcontrol
167

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
