24.4Cameracontrol
Powerupandstandby
Whenthebreakerconnectingpowertothecamerais
switchedon,thecamerawillrunabootupsequence
lastingforabout1minute,afterwhichthecamera
willbeinStandbymode.
Inorderforthecameratooperate,youmustbring
thecameraoutofstandbymodeusingthecamera
controls.
Thermalcamerastandby
Standbymodecanbeusedtotemporarilysuspend
thethermalcamera'sfunctionswhenthecamerais
notneededforaprolongedperiod.
Wheninstandbymodethecameradoesnotprovide
alivevideoimage.
Enablinganddisablingthermalcamerastandby
Withthethermalcameraapplicationdisplayed:
1.SelectMenu.
2.UsetheStandbymenuitemtoswitchthecamera
inandoutofstandbymode.
Note:Youcanalsouseanyofthecameracontrols
inthethermalcameraapplicationto“wake”the
camerafromstandbymode.
Pausingthethermalcameraimage
Withthethermalcameraapplicationdisplayed:
1.SelectMenu.
2.SelectPauseImage.
24.5Imageadjustments
Adjustingthethermalcameraimage
Withthethermalcameraapplicationdisplayed:
1.SelectMenu.
2.SelectAdjustContrast.
3.SelecttheContrast,Brightness,orColoroption
asappropriate.
Therelevantnumericadjustcontrolisdisplayed.
4.Adjustthevalueasrequired.
5.SelectBackorOktoconrmthenewvalue.
Thermalcamerascenepresets
Scenepresetsenableyoutoquicklyselectthe
bestimagesettingforthecurrentenvironmental
conditions.
Duringnormaloperationthethermalcamera
automaticallyadjustsitselftoprovideahigh-contrast
imageoptimizedformostconditions.TheScene
presetsprovide4additionalsettingsthatmay
providebetterimageryincertainconditions.The4
modesare:
NightRunning—scenepresetmodefor
nightconditions.
DayRunning—scenepresetmodefor
daytimeconditions.
NightDocking—scenepresetmodefor
nightdocking.
Search—scenepresetmodeforidentifying
peopleorobjectsinthewater.
Althoughthepresetnamesindicatetheirintended
use,varyingenvironmentalconditionsmightmake
anothersettingmorepreferable.Forexample,the
nightrunningscenepresetmightalsobeusefulwhile
inaharbor.Youmaynditbenecialtoexperiment
withthedifferentscenepresetstodiscoverthebest
presettousefordifferentconditions.
Changingthethermalcamerascenepreset
Withthethermalcameraapplicationdisplayed:
1.SelectMenu.
2.SelectImageOptions.
3.UsetheScenemenuitemtoswitchbetweenthe
availablescenepresets,asappropriate.
Thermalcameracolormodes
Arangeofcolormodesareavailabletohelpyou
distinguishobjectson-screenindifferentconditions.
Changingthecolormodeswitchesthethermal
cameraimagebetweenagreyscalemodeand1
ormorecolormodes.Thereare5colormodes
available.
Thefactorydefaultcolormodeiswhite,whichmay
improveyournightvision.Thisdefaultmodecanbe
changedifrequiredusingthecamera'son-screen
VideoSetupmenu.
370aSeries/cSeries/eSeries

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
