13.1Manoverboard
Ifyouloseapersonorobjectoverboard,youcan
usetheManOverboard(MOB)functiontomark
thepositionthatthevesselwasatwhentheMOB
functionwasactivated.
TheMOBfunctionisavailableatalltimes,regardless
ofwhichapplicationisrunning.MOBcanbesetto
DeadReckoningorPositionmode.DeadReckoning
modewilltakeintoconsiderationtheeffectsofwind
andtides.Thisusuallyprovidesamoreaccurate
course.Positionmodedoesnottakethesefactors
intoaccount.
ToobtainaMOBposition,yourmultifunctiondisplay
musthaveaGPSpositionx.Ifyou'reusingdead
reckoning,headingandspeeddatamustalsobe
available.
WhenMOBisactivated:
•AnaudibleMOBalarmissoundedevery30
secondsuntiltheMOBiscancelled.
•AnMOBalarmdialogisdisplayeduntilitis
acknowledged.
•ThesystemsendsMOBalarmstootherRaymarine
equipment.
•TheactiveChartapplicationischangedtoa
low-detail2Dview,withaninitialrangeof15m
(50ft).MotionmodeissettoAutoRange.As
thevesselmovesawayfromtheMOBpositiona
dottedlineisdisplayed,joiningtheMOBposition
withthevessel'sposition.
•Theactiveradarapplicationrangeischangedto
230m(760ft).
•AllGotoandFollowfunctionsaredisabledinall
applications.Navigationtoanyactivewaypoint
isstoppedandanyexistingnavigationfunctionis
cancelled.
•Ifpositionorheadingandspeedinformationis
availableaMOBwaypointisplacedatthecurrent
vesselpositioninanyapplicationthatiscapableof
showingwaypointsandvesselposition.
•MOBdataisdisplayedinthedatabar,replacing
theexistingdata.
•MOBdataisdisplayedonthehomescreen,
replacingthestatusicons.
WhentheMOBalarmiscancelled:
•MOBdataisremovedfromtherelevant
applications.
•Thechartapplicationmotionmodeisreset.
•Thechartiscenteredonthevesselandpitch/
rotationsettodefault.
•GOTOandroutefunctionsarerestored.
•Thedatabarmodeisreset.
•AMOBnormalmodesignalissenttoany
instrumentonSeaT alk.
Waypoint(MOB)button/icon
Dependingonthemultifunctiondisplayvariant
therewillbeeitheraWaypoint(MOB)buttonoran
on-screenicon.
WPT
button
•cSeries
•eSeries
•RMK-9keypad
WPT
icons
•aSeries
•gSSeries
Throughoutthismanualtheterm:SelectWPT,refers
topressingthephysicalWPTbuttonorpressingthe
on-screenWPTicon.
Activatingthemanoverboard(MOB)alarm
Onmultifunctiondisplayswithphysicalbuttonsor
whenusingaremotekeypadyoucanusetheWPT
(MOB)buttontoactivatetheMOBalarm
1.PressandholdtheWPT/MOBbuttonfor3
seconds.
Activatingthemanoverboard(MOB)
alarm—Touchonlydisplays
OnaTouchonlydisplayyoucanusetheonscreen
WPT(MOB)icontoactivatetheMOBalarm
1.PressandholdtheonscreenWPT/MOBicon
for3seconds.
186aSeries/cSeries/eSeries

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
