00-00-00
Effectivity 912/914 Series
Edition 1 / Rev. 0
page 23
May 01/2007
d02620
BRP-Rotax
Maintenance Manual
7) Safety notice
Although the mere reading of such information does not eliminate the hazard, your
understanding and application of the information will promote correct use.
The information and components/system descriptions contained in this Maintenance
Manual are correct at the time of publication. BRP-Rotax maintains a policy of
continuous improvement of its products, without, however, incurring any obligation to
install them on its products previously manufactured.
BRP-Rotax reserves the right to discontinue or alter any specification, design, detail,
model or equipment, at any time and without incurring obligation.
The illustrations in this Maintenance Manual show the typical construction. They may
not correspond to every detail or the exact shape of the actual parts, but show parts
which have the same or similar function.
Specifications are given in the SI metric system with the USA equivalent in parenthesis.
7.1) Repeating symbols
This Manual uses the following symbols to emphasize particular information.
These indications are important and must be respected.
â–² WARNING: identifies an instruction which, if not followed, may cause
serious injury including the possibility of death.
â– CAUTION: Denotes an instruction which, if not followed, may severely
damage the engine or other component.
â—† NOTE: Indicates supplementary information which may be needed
to fully complete or understand an instruction.
XXX
In various illustrations, this symbol indicates the location of the
serial number on a component.
4 In the illustrations concerned, this symbol indicates the position
of the serial component number (e.g. on crankshafts, cam-
shafts).
VT06 In the illustrations concerned, a fourdigit combination of letters
and numbers indicates a control point which needs to be
checked. See the corresponding dimension sheets for the
correct value.
