Rotax 912 Series Service Manual

Effectivity 914 Series
Edition 1 / Rev. 0
76-00-00
page 55
May 01/2007
d02626
BRP-Rotax
Maintenance Manual
06750
Motor / Engine type: ___________ Motor / Engine serial no.: ___________ TCU Serien-Nr. TCU serial no. ____________ TCU Teile Nr. TCU part no.: ____________ TCU Programmversion TCU Program-Version: Sichtkontrolle: Visual check: ____________ Prüfdongle, Serien-Nr.: Check dongle, serialno.: ____________ Prüfung mit: Check with: Vergaser 2/4, Serien-Nr.: carburetor 2/4, serial no.: ____________
ROTAX Testkoffer am Motor ROTAX testcase on engine
Unterschrift Prüfer / Signature Tester: _____________ Datum/Date: ________
Bemerkungen / Remarks: ______________________________
__________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________
TSN: ______ TSO: ______
Lampenkontrolle / lamp control
Lampen
leuchten beim Einschalten:
lamps flash during switch on:
gelbe Lampe rote Lampe yellow lamp red lamp
Anreicherungsventilkontrolle / solenoid control
Solenoid
schaltet bei :
solenoid operates at :
1250 mbar
(966 470)
Over Boost-Kontrolle / over-boost-control
rote Lampe leuchtet bei :
red lamp flashes at :
O.K.
Airboxdruck >1550 mbar airbox pressure >1550mbar
Prüfprotokoll für Turboladerregler / Inspection protocol for turbocharger control unit
Plausibiltäts-Kontrolle / plausibility-control (MONITOR-Oberfläche / MONITOR-menu)
LOAD
1)
(idle): 0÷10 % (Sollwert/target value) _________ %
LOAD
1)
(full): 115 % (Sollwert/target value) _________ %
ambient pressure
2)
: _________ mbar
airbox pressure
2)
: _________ mbar
airbox temperature
3)
: _________ °C
servoposition (idle)
4)
: 100 %
±
3 (Sollwert/target value) _________ %
1)
lineare Kennlinienverlauf / linear values of load
2)
+/- 10 mbar Differenz der beiden Werte (vgl. Tagesdruck) /
+/- 10 mbar difference between the two values (compare actual pressure of the day)
3)
die Temperature sollte in etwa der Umgebungstemperatur entsprechen /
temperature should be equal to ambient temperature
4)
Servoposition bei IDLE = 100% Servoposition = Waste-Gate geschlossen /
Servoposition at IDLE = 100% servoposition = Waste-Gate closed
Kalibrier-Kontrolle / calibration-control
966 470 966 473
966 741
TSN: ______ TSO: ______
1260 mbar
(966 473 / 966 741)
Airboxdruck Airbox pressure
10
1003
60
710
12219
250
6720
-37
60
900
60
710
12219
250
6720
-37
TLR 4.3
TLR 4.5 TLR 4.6
TLR 4.3 TLR 4.5 TLR 4.6
Fig. 76-52
4) Form Sheets
