GAME BOARD
101
16
Beforecommencinganyworkbesuretoremovethepowerfromthemachine
anddisconnectthepowercord.Failuretodosomay resultinanelectric
shock.
16-1 GAME BOARD - LOCATION
●Whenreturningthegameboardaftermakingrepairsorreplacements,
makesure that there are noerrors in the connectionof connectors. Erroneous
connectionscanleadtoelectricalshock,shortcircuitsorres.
●Whenconnectingaconnector,checkthedirectioncarefully.Connectorsmust
beconnectedinonlyonedirection.Ifindiscriminateloadsareappliedinmaking
connections,theconnectororitsterminalxturescouldbedamaged,resultingin
electricalshock,shortcircuitsorres.
To access the GAME BOARD.
1
Locate and remove the 6x M6x20 HEX BOLT BLK (3 each side) from around the SEAT BASE.
2
Using 2 people, carefully raise the seat and disconnect the harnessing from underneath.
6x M6x20 HEX BOLT BLK
(3 each side)
