122
P
ARTS LIST
19
8
ASS
Y MO
N
ITO
R M
AS
K (
P
D
-
1
300
X
U
K
)
(D
-
1/
1
)
ITEM NO
PART NUMBER
DESCRIPTION
QTY
****1
PD-1301UK
MASK MONITOR
1
****2
PD-1304UK
BRKT MASK UPPER
1
****3
PD-1305UK
BRKT MASK LOWER
1
****4
PD-1308XUK
GLASS 42 LCD PROTECTIVE
1
****101
OS1230
FOAM STRIP 2MM X 10MM
2m
****201
000-P00410-W
M4X10 MSCR PAN W/FS PAS
5
1
2
3
4
101
201
201
130
132
