Conrm that the main switch is at OFF.
6-3 POWER SUPPLY, AND GROUND CONNECTION
• Usethepowersupplyequippedwithanearthleakagebreaker.Useofpower
supplywithoutsuchabreakercouldresultinreifthereisacurrentleakage.
• Haveavailable a securely grounded indoor ground terminal. Without proper
grounding, customers could be electrocuted and product operations might not
alwaysbestable.
• Donotexposethepowercordorgroundwire.Iftheseareexposed,customers
could stumble over them, for instance, and easily damage them. Additionally, if
theselinesaredamaged,therecouldbeariskofelectricalshockorshortcircuit.
Set these lines at locations where they will not interfere with customer trafc, or
attachcoverstothem.
• Afterlayingoutthepowercordontheoor,besuretoalwaysprotectit.Ifthe
powercordisleftexposed,itcaneasilybedamaged,resultinginelectricalshock.
USE ONLY 250V FUSES
Mains Switch shown in
OFF position
Lan Network Connector
Mains ON/OFF Switch
IEC Inlet
