PART DESCRIPTIONS
11
4
4 PART DESCRIPTIONS
Assembly Billboard
Monitor Cover Left
Assy Control Panel
Assy LCD Display
Seat Woofer
Assy Coin Tower
Assy Seat
Mon Cover R
Speakers
Billboard Plaque
Assy Base Box
Gear Shift
