Description of the device
4.5 Components of the product
SCALANCE X-300
102 Operating Instructions, 05/2016, A5E01113043-20
● With devices with power supply 100 to 240 VAC / 60 to 250 VDC:
– A 3-pin terminal block (or two terminal blocks for redundant power supply) for the
signaling contacts.
– A 3-pin terminal block (or two terminal blocks for redundant power supply) for the
power supply.
● With devices with 24 to 48 VDC power supply:
– A 2-pin terminal block (or two terminal blocks for redundant power supply) for the
signaling contacts.
– A 4-pin terminal block (or two terminal blocks for redundant power supply) for the
power supply.
Components of the X308-2M PoE product
Interfaces
RJ-45 port electrical
10/100/1000 Mbps
Components of the product
The following parts ship with a SCALANCE X-300M PoE:
● Device with C-PLUG exchangeable medium
● 4-pin terminal block for the power supply
● 2-pin terminal block for the signaling contact
● Product CD with documentation and software
