4.5 Components of the product
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
103
4.5.7
Components of the XR-324-4M PoE product
Components that ship with the SCALANCE XR324-4M PoE and XR324-4M PoE TS switches
The following components ship with a SCALANCE XR324-4M PoE or XR324-4M PoE TS:
● Device with C-PLUG exchangeable medium
● 2 mounting brackets and 8 screws (M3x5 recessed head, drive: Torx) for 19" rack
installation
● Connecting cable for the diagnostics port
● Product CD with documentation and software
● For devices with a 100 to 240 VAC power supply:
– A 2-pin terminal block for the power supply
– A 2-pin terminal block for the signaling contact
● With devices with 24 V DC power supply:
– 4-pin terminal block for the power supply
– 2-pin terminal block for the signaling contact
– 4 adhesive feet for desktop mounting
4.5.8
Components shipped with the MM900 product
The following components are supplied with a SCALANCE MM900 media module:
● MM99x-2xx media module
Note
Identification labels
The location labels identify the media modules and ship with the SCALANCE device.
4.5.9
Components shipped with the SFP product
Table 4- 3 Overview of the components shipped with the
SFP
product group
Device:
Transceiver
(Variant)
Plug-in terminal block
Device
Product CD
(signaling contact)
2-pin
(24V)
4-pin
SFP991-1
(-)
-
-
●
-
SFP991-1LD
(-)
-
-
●
-
SFP991-1LH+
(-)
-
-
●
-
