Introduction
2.2 Product overview
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
27
Type designations
Structure of the type designation
The type designation of an IE Switch X-300 is made up of several parts that have the
following meaning:
Interfaces of devices without optical ports:
Electrical RJ-45 port for 10/100 Mbps.
Electrical RJ-45 port for 10/100 Mbps or 10/100/1000 Mbps.
Interfaces of devices with optical ports:
SC port 100 Mbps multimode FO cable (up to max. 5 km).
SC port 100 Mbps single mode FO cable (up to max. 26 km).
SC port 1000 Mbps multimode FO cable (up to max. 750 m).
SC port 1000 Mbps single mode FO cable (up to max. 10 km).
LH SC port 1000 Mbps single mode FO cable (up to max. 40 km).
SC port 1000 Mbps single mode FO cable (up to max. 70 km).
If information applies to all devices, the term "IE Switches X-300" is used. If information
applies to only a particular product group, the relevant names will be used without extra
