Siemens SCALANCE X308-2 User Manual

Technical specifications
8.2 X-300 technical specifications
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
157
8.2.1
Construction, installation and environmental conditions
Table 8- 1 Construction
Device variant
Dimensions (W x H x D)
Weight
Degree of protec-
tion
X304-2FE,
X306-1LD FE
60 × 125 × 123 mm 700 g IP30
X307-3,
X307-3LD,
X308-2,
X308-2LD,
X308-2LH,
X308-2LH+,
X310,
X310FE,
120 × 125 × 123 mm 1400 g IP30
X320-1FE,
X320-3LD FE
180 × 125 × 123 mm 1650 g IP30
Table 8- 2 Installation options
Device variant
Installation options
X304-2FE,
X306-1LD FE
• DIN rail
• S7-300 standard rail
• Wall
X307-3,
X307-3LD,
X308-2,
X308-2LD,
X308-2LH,
X308-2LH+,
X310,
X310FE,
X320-1FE,
X320-3LD FE
• DIN rail
1)
• S7-300 standard rail
• Wall
1)
Note: When used in shipbuilding, installation on a 35 mm DIN rail is not permitted. In ships, the 35
mm DIN rail does not provide adequate support.
